CNC Routing & Engraving Services

Bay Rubber Company’s CNC Routing and CNC Engraving Services add additional depth and dimension to specialized parts and assemblies. Materials are no longer constrained to two dimensions like traditional steel ruled die cutting; tool path options increase customization for materials up to 6”. CAD software and CNC processing hardware updates allow for seamless integration and execution of new parts. Bay Rubber’s CNC Routing & engraving services include drawing importation and revision updates, material selection & storage, tool pathing, and material processing using a gantry mill style CNC router and engraver.

CNC Router Cutting Applications

Gaskets

3D Carving

Aluminum Fabrication

Architectural Millwork

Woodworking Applications

Aerospace

Aerospace Cabinetry

Exhibits and Fixtures

Sign Making

CNC Router Cutting and Engraving Materials

Acrylic

Wood

ACM

Copper

Brass

Aluminum

PVC

Foam

MDF

Composite

CNC Router Cutting and Engraving Materials

Drawing Importation and Revision Updates

Material Selection & Storage

CNC Router Services: Material Processing

Tool Pathing

Drawing Importation and Revision Updates

Submit drawings and designs to info@bayrubber.com for rapid quoting or use our secure file upload link, and an expert will review your request.

Drawing importation includes a review of all MBD features, tolerances, and additional spec call-outs required to produce the proper part. Once the first article has been accepted, the drawing file can be called upon to manufacture any quantity desired. Revision updates are simple and straightforward. Just resubmit updated drawings with a new revision number, and following a thorough review, new parts are stored along with older parts.

Material Selection & Storage

Material selection is a key factor for the success of a product in its intended application. Critical factors include appearance, performance, chemical compatibility, temperatures range and more. Proper material selection will guarantee extended service life and operation of the component as well as the system in which it functions.

Material storage is simple at Bay Rubber Company. We have an ideal environment for storing and maintaining inventory of gasket material and sheet rubber products. Customers can access our stock items or have custom formulations warehoused until parts can be cut from it. Customers have the option to supply materials for processing.

CNC Router Services: Material Processing

Processing occurs at our California headquarters. Material characteristics and thickness will be the most critical factors in processing speed and throughput. Nesting software automatically reduces material waste and increases efficiency. Automatic tool changing increases processing capabilities and reduces downtime between operations.

Working Parameters:

Work Area: 60” x 120”
Gantry: 6” Clearance, 60” Wide Width
Spindle: PDS 7.5 HP ADES90 Spindle
Z-Carriage: Electric Oscillating Knife

Tool Pathing

Toolpaths are the information that the milling machining uses to direct the tool through the material. Toolpaths must be carefully defined to minimize imperfections and poorly performing parts. Bay Rubber Company is an expert in subtractive manufacturing processes and has extensive knowledge in removing material safely and producing parts that exceed minimum tolerance requirements using CNC Routing methods.

Common Toolpaths Include

Bay Rubber Company’s commitment to quality promises we develop, produce and deliver products and services that consistently conform and exceed our customer’s expectations. We are dedicated to the pursuit of quality and error free production through quality management systems and high standard quality inspection strategies.

The parallel toolpath moves the tool in equally spaced parallel passes in the XY Plane across the surface.

The surface contour toolpath works much like a topographical map, cutting along a series of paths at incremental heights (stepdowns). As a surface becomes steeper the paths get closer together: as a surface becomes shallower, the paths are spaced farther apart. For this reason, it is generally unsuitable for clearing material from a horizontal surface, but is excellent for removing material from vertical or very steep surfaces prior to other finish toolpaths.

The toolpath moves the tool over the surface in a spiral motion, from the inside-out or the outside-in. The step over is a fixed amount, but is calculated parallel to the surface at the location being milled (rather than in the XY plane as with the parallel toolpath. It will make small pockets in some places, if necessary.

Cuts all selected surfaces independently of one another in spirals from the inside-out or the outside-in. The outside of the toolpath follows the edge of the surface exactly, so there is no scalloping left on the vertical faces between surface edges.

The contour toolpath can be used to direct the tool cut along a curve. The curve can be planar or 3D.

The pocket toolpath removes material from within a closed curve, creating recessed areas with flat-bottoms.

Points are used to define drill toolpaths. Drilling can be done to a predetermined depth, or points can be projected onto a 3D surface and the drill will drill to the depth of those points.

Acceptable File Types

STL

3D DXF

OBJ

3DS

VRML

3DM

SKP

Import 3D Mesh files created in other CAD software such as, Rhino, Solidworks, AutoCAD, Silo, MOI, Blender, SketchUp, etc.

For additional information about how Bay Rubber CNC Routing Services and CNC Engraving Services can improve your projects please contact us today.

Why Choose Bay Rubber Company for CNC Routing & Engraving

Bay Rubber Company delivers accurate, consistent results by combining skilled technicians with advanced equipment, including a precision CNC router and engraver supported by a rigid gantry mill setup. Our CNC Routing services handle simple to complex parts with clean edges, tight tolerances, and reliable turnaround times. Customers choose Bay Rubber Company for dependable workmanship, clear communication, and the ability to support prototypes or full production runs with the same level of care.

Getting started is easy—send us your drawing or model, and we’ll review your details to provide a fast, accurate quote. For the best results, include material type, thickness, quantities, and any critical dimensions. Bay Rubber Company is ready to assist with your CNC Routing and engraving needs and help you choose the best approach for your project. Contact us today.

Contact us today and let us show you what we can do for your operation.
